Overview

We measure and verify road condition and geometry using mobile LiDAR, profilers, and imaging. Our workflows compute IRI/roughness, rutting, crossfall/superelevation, lane and shoulder widths, curb & gutter position, vertical/side clearances, and sight distance delivered as CAD/GIS layers with a rigorous QC report.

Relative Precision

±10–20 mm

Absolute Accuracy

±2–5 cm*

Pavement Density

≥ 500 pts/m²

Capture Mode

Traffic-speed

Imagery

Panoramic/RGB optional

*Depends on GNSS conditions and control/checkpoint strategy.

Metrics & Tests

Ride & Surface

IRI/roughness indices (per lane)
Rut depth; crossfall/superelevation
Texture indicators (LiDAR/imagery-derived)

Geometry & Safety

Lane/shoulder widths, curb & gutter, edge drop
Vertical/side clearances (bridges, signage, barriers)
Sight-distance & envelope checks

Compliance

Design tolerance checks vs. alignment
Change detection vs. previous surveys
Construction lot acceptance (QA/QC)

Deliverables

Core Data

Classified point clouds (LAS/LAZ) incl. curb/edge
DTM/DSM, contours, slope & hillshade rasters
Colorized point clouds and orthophotos (optional)

Engineering Products

IRI, rutting, crossfall, width maps (GeoTIFF/SHP)
Cross-sections, profiles, and clearance reports
Feature extraction: lane lines, signage, barriers, markings

Formats

LAS/LAZ GeoTIFF DWG/DXF SHP/GDB CSV PDF maps

Workflow

Route planning & safety plan; control layout
Acquisition: mobile LiDAR + profilers at traffic speed
Trajectory solution: GNSS/IMU PPK/PPP (SLAM if needed)
Strip alignment: boresight, overlap residuals, bundle adjustment
Cleaning & classification: pavement, curb/edge, obstacles
Computation: IRI, rutting, crossfall, widths, clearances
Packaging: CAD/GIS layers, profiles/sections, maps
QA/QC report: checkpoints, RMSE, density, conformance

Technology

Sensors

High-rate multi-return LiDAR (up to ~1M pts/s)
Inertial profilers & wheel odometry
Panoramic/RGB cameras for inventory & markings

Positioning

Tightly coupled GNSS/IMU with PPK/PPP
Local control & independent checkpoints
SLAM assistance in GNSS-poor areas (as required)

Software

TerraScan LP360 ArcGIS Global Mapper iTwin Custom QA scripts
